NanoTDB – Golang Append-Only Time Series DB

A small, embedded time-series database designed for resource-constrained hosts (Raspberry Pi, edge nodes, IoT gateways). No external dependencies at runtime. All data lives in plain files under a single root directory. Architecture overview Engine ├── "prod" Database → WAL (prod.wal) + Catalog (catalog.json) + partitioned .dat files ├── "sensors" Database → WAL + Catalog + partitioned .dat files └── "internal" → engine self-metrics (same layout, never exposed to users) The Engine is the single entry point. It owns a collection of named databases and routes ingested samples to the right one based on the line-protocol prefix. Each Database has three storage layers: Layer File Purpose WAL .wal Crash-safety: records every sample before it enters the page Catalog catalog.json Maps metric names ↔ compact MetricIDs + value types Data files data-.dat Immutable compressed pages flushed from memory Data flow Ingest (AddLine) AddLine("prod/room.temp 21.5 1715000000000000000") │ ├─ parse line protocol → dbName="prod" metric="room.temp" ts=… value=21.5 ├─ getOrCreateDB → open or reuse prod Database ├─ WAL append → write compact record to prod.wal (crash-safe) ├─ addToOpenDay → append to in-memory Page for today's bucket └─ if page full → compress + write page frame to data-.dat reset WAL (replay no longer needed) Timestamps must be monotonically non-decreasing per metric across the entire write stream. Out-of-order or stale samples are rejected. Replay (on engine open) When a database is opened, the WAL is replayed into the in-memory page if the data file is behind. The catalog is used to resolve ValueTypes for metrics that omit them (compact format optimization). After a full replay the engine is ready to accept new writes. Query (QueryRange) QueryRange("prod", "room.temp", fromTS, toTS, stride, callback) │ ├─ iterate UTC days in [fromTS, toTS] │ ├─ open data-.dat → scan page frame headers │ │ skip frames outside time window (no decompression) │ │ decompress + scan matching frames │ └─ check in-memory page for today's data └─ call callback for each sample (every Nth if stride > 1) Line protocol DB/metric.name value [ts] DB — database name (created automatically on first write) metric.name — arbitrary metric identifier (slash-separated namespaces work well) value — integer (42, -7) or float (3.14, 1e-3). An integer literal always creates an int32 metric; a float literal creates a float32 metric. Type is fixed on first write; mixing types for the same metric is an error. ts — Unix nanosecond timestamp (optional; defaults to time.Now()) Examples: prod/room.temp 21.5 1715000000000000000 sensors/pressure.hpa 1013 internal/batch.size 256i The i suffix forces integer interpretation for values that look like floats. WAL format (compact v2) Each record is a uvarint length prefix followed by a fixed-layout payload: [uvarint: payload_len] [payload] Payload layout: Offset Size Field 0 2 MetricID uint16 LE 2 3 TS delta uint24 LE nanoseconds from baseline 5 1 CompactTL flags bit 7 = new baseline, bit 6 = new metric 6 8 Baseline TS int64 LE (only when bit 7 set) — var name_len+name+vtype (only when bit 6 set) — 4 Value int32 or float32 LE, always present Hot path (known metric, same baseline): 2+3+1+4 = 10 bytes + 1 varint = 11 bytes. A new baseline is emitted on the first record of each WAL and whenever the timestamp gap exceeds ~16.7 ms (2²⁴ ns). Typical sensor streams fit hundreds of seconds between baseline resets. Known metrics (previously seen in the session) omit the name and value type; those fields are recovered from the catalog during replay. On-disk layout / engine.toml — engine configuration (auto-created on first start) / catalog.json — metric registry: name → id + type manifest.toml — per-database settings (retention, WAL, page limits) .wal — write-ahead log (single reusable file) data-.dat — compressed page frames for completed partitions Data files are append-only sequences of page frames: Frame = PageHeader(18 bytes) + compressed_len(uvarint) + S2-compressed payload + CRC32(4 bytes) The payload is a flat array of interleaved (MetricID, Timestamp, Value) triples, sorted by timestamp. S2 compression typically achieves 3–4× on realistic sensor data. Configuration (engine.toml) Created automatically at /engine.toml on first start. Key settings: Key Default Effect engine.listen :8428 HTTP server address wal.max_segment_size 67108864 (64 MiB) WAL size before reset after a page flush wal.fsync_policy segment segment = fsync on WAL reset; always = fsync every append durability.profile strict strict / balanced / throughput (see below) stats.enabled true Emit engine self-metrics to the internal database stats.interval 30s How often stats are flushed Durability profiles: Profile Page file fsync Catalog fsync strict yes yes balanced yes no throughput no no Per-database settings (retention, partitioning, WAL skip window, page flush thresholds, rollups) live in /manifest.toml and default values can be set in engine.toml under [manifest_defaults]. Partition options in [retention]: partition = "day" (default): data-YYYY-MM-DD.dat partition = "month": data-YYYY-MM.dat partition = "year": data-YYYY.dat partition = "forever": data-forever.dat Rollups (manifest.toml) Rollup jobs are defined in the source database manifest under [rollups]. Example: [rollups] enabled = true checkpoint_file = "rollup.checkpoints.log" default_grace = "5m" [[rollups.jobs]] id = "outside_temp_1h" source_metric = "temp.out_dry" interval = "1h" aggregates = ["min", "max", "sum", "avg", "count"] destination_db = "sensors_rollup_1h" destination_metric_prefix = "temp.out_dry" Rollup config reference: Field Scope Required Valid / Default Notes rollups.enabled DB no `true false(defaultfalse`) rollups.checkpoint_file DB no string (default rollup.checkpoints.log) Checkpoint log path, relative to source DB directory. rollups.default_grace DB no Go duration or empty Used when job grace is omitted. rollups.jobs[].id Job yes non-empty string Unique per source DB for checkpoint tracking. rollups.jobs[].source_metric Job yes non-empty string Metric to read from source DB. rollups.jobs[].interval Job yes valid Go duration (>0) Rollup bucket size (for example 1h, 24h). rollups.jobs[].aggregates Job no `min max rollups.jobs[].destination_db Job yes non-empty string Target DB receiving rollup samples. rollups.jobs[].destination_metric_prefix Job no string (default source_metric) Output names are .. rollups.jobs[].grace Job no Go duration or empty Overrides default_grace for this job. Notes: Checkpoints are stored in the source DB (default rollup.checkpoints.log). Destination DBs can also define their own rollup jobs to create cascades (for example 1h -> 1d). For low-frequency rollup outputs, use coarser partitions on destination DBs (for example month or year) to avoid many tiny day files. Binaries nanotdb — server nanotdb --config start server using given engine.toml nanotdb --init --config write default engine.toml and exit Exposes a small HTTP API compatible with the VictoriaMetrics instant/range query wire format (/api/v1/query, /api/v1/query_range, /api/v1/import/prometheus). nanocli — offline CLI tool Operates directly on the data directory without a running server. nanocli inspect db --root [--db ] [--json] — overview of all/one database nanocli inspect dat --root --db [--json] — page frame headers in .dat files nanocli inspect wal --root --db [--json] — WAL record dump nanocli import --root --in [--json] — bulk import line-protocol file nanocli export --root --db [--out ] — export database to line protocol (stdout when --out is omitted) nanocli query --root --db --metric [--start ] [--end ] [--format table|json] LP timestamps (import and exported files) accept / use: YYYY-MM-DD HH:MM:SS.nnnnnnnnn (UTC) and also accept raw Unix nanoseconds on import. --start / --end accept RFC3339 strings, YYYY-MM-DD [HH[:MM[:SS[.nnnnnnnnn]]]], or Unix timestamps (seconds or nanoseconds). Rollup full-cycle check script For deterministic end-to-end verification (generate LP -> import -> rollups -> export -> compare expected), run: ./scripts/rollup_full_cycle_check.sh Optional arguments: ./scripts/rollup_full_cycle_check.sh Defaults: root-dir=test-data/full-cycle-check, duration-hours=30, metrics=10, cadence-seconds=10, gap-metrics=2 Generated artifacts are placed in /work for easy discovery: scenario_summary.json (duration, rates, counts, per-metric stats) known_gaps.csv (deterministic missing windows for temp.gap_probeXX metrics) SCENARIO.md (quick human-readable summary) Engine API (embedding) e, err := engine.OpenEngine("/data", 0) // 0 = default WAL segment size defer e.Close() // Ingest err = e.AddLine("sensors/temp 22.1 " + strconv.FormatInt(time.Now().UnixNano(), 10)) // Range query err = e.QueryRange("sensors", "temp", fromTS, toTS, 1, func(s engine.Sample) error { fmt.Println(s.TS, s.Float32) return nil }) // Last value (from in-memory catalog cache) sample, ok, err := e.QueryLast("sensors", "temp") // Bulk import / export err = e.ImportFile("backup.lp") err = e.ExportFile("sensors", "backup.lp") Key types: Type Description Engine Top-level coordinator; safe for concurrent use Database One named DB with WAL + catalog + data files Catalog Metric name ↔ ID registry; persisted as JSON Page In-memory buffer of interleaved samples; flushed when full WAL Single-file write-ahead log with compact v2 encoding Sample Decoded data point from a query Timestamp int64 Unix nanoseconds MetricID uint16 per-database metric address
