I designed a nibble-oriented CPU in Verilog to build a scientific calculator

This project implements a fully functional scientific calculator in hardware using an FPGA. It includes a custom soft CPU, microcode firmware, and supporting tools. For the full story, see the blog. Try it in a web browser: Without debugger With debugger Project Structure Folder Description verilog/ SystemVerilog source files for the CPU, ALU, I/O, and test benches ucode/ Microcode (firmware) for the soft CPU quartus/ Quartus project files for FPGA synthesis modelsim/ ModelSim simulation setup Qt/ Qt-based simulator and debugger (uses Verilator) calctest/ Command-line test harness for hardware verification (uses Verilator) tools/ Assembler and script compiler for the microcode Pathfinding/ Algorithm research and verification projects Quick Start The fastest way to try the calculator is to build the Qt simulator: # From WSL2 cd /mnt/c/Projects/FPGA-Calculator/verilog make qt Then open Qt/Calculator.pro in Qt Creator and build for "Desktop Qt MSVC2022 64 Bit". See the verilog/ and Qt/ folders for detailed instructions. Required Tools Install these tools depending on your target: Tool Purpose Notes Verilator Verilog simulation Required for Qt simulator Qt Desktop/WebAssembly/Android app Version 6.9+ Quartus FPGA synthesis Version 13.0 SP1 for Cyclone II ModelSim Waveform simulation Optional Visual Studio 2022 C++ compiler for Qt Community Edition Python 3 Assembler and tools Verilator Setup Verilator runs in WSL2 (Windows Subsystem for Linux). The project source files reside on a Windows partition and are accessed from WSL2. Target Verilator Version Notes Desktop (Qt/MSVC) 5.x (latest) Recommended WebAssembly 4.228 Required (no thread support) # Install prerequisites sudo apt-get install build-essential autoconf flex libfl-dev bison # Clone and build Verilator git clone https://github.com/verilator/verilator cd verilator git checkout v5.042 # For Desktop, or v4.228 for WebAssembly autoconf ./configure make -j8 make test # Set environment (add to .bashrc for persistence) export VERILATOR_ROOT=$(pwd) Optionally install GtkWave for viewing waveforms: Build Targets Target Command Description Qt Simulator make qt in verilog/ Build for Qt desktop application Calctest make calctest in verilog/, then make in calctest/ Command-line test harness ModelSim make test_self in verilog/ CPU self-test for ModelSim FPGA Hardware make revB in verilog/ Assemble microcode for RevB board See the README files in each subfolder for detailed build instructions: verilog/README.md - Verilator simulation and microcode assembly calctest/README.md - Command-line test harness for hardware verification quartus/README.md - FPGA synthesis and programming ucode/README.md - Microcode source files Pathfinding Projects Independent research and verification projects: Folder Description Pathfinding/Proto/ BCD arithmetic golden reference for hardware verification (submodule) Pathfinding/Proof/ Proofs of concept for complex operations using basic arithmetic Pathfinding/Methods/ C++ implementations of calculator algorithms (deprecated) Pathfinding/Input/ Numerical input state machine simulation Pathfinding/Mockup/ Keyboard layout design and user interaction testing License This project is licensed under the Creative Commons Attribution-NonCommercial-ShareAlike 4.0 International License. You are free to: Share - copy and redistribute the material in any medium or format Adapt - remix, transform, and build upon the material Under the following terms: Attribution - You must give appropriate credit and indicate if changes were made NonCommercial - You may not use the material for commercial purposes ShareAlike - Contributions must be distributed under the same license
